SimPal-D310 GSM Gate Opener
SimPal-D410 4G LTE Gate Opener work on 4G LTE network, SMS or calling to open electricity door or gates.
12V DC power input, two 16A latching relay can be use to control two lines signal.
Cable temperature sensor included for temperature monitor, thermostat control etc.
NO/NC type wired sensor input to work with wired smoke detector, wired water leakage etc sensors.
Max stored 200 calling numbers.
Compact design and DIY installation. Good choice for electricity gate opener, heater controller, industrial power control etc.
Working accessories: DTS-002
Technical Specification:
|
Product Size |
113×72×30 mm |
|
GSM frequency |
900/1800 Mhz |
|
Power input |
12V DC 1A |
|
Relay control |
SMS or phone calling |
|
Relay type |
16A Latching relay 2pcs |
|
Max loading |
16A 3500W |
|
SIM card |
PUSH SIM slot, Normal Size SIM 1.8V/3.0V socket |
|
Indicators |
Three blue LED, GSM indicator/Line1 output/Line2 output |
|
Temperature sensor |
DS18B20, -30—100 degree |
|
Wired sensor type |
NO/NC trigger (no power input) |
|
Standby power consumption |
20 mA |
|
Operating temperature |
-30~+50℃ |
Packing content:
GSM Gate Opener: 1PCS
Cable Temperature Sensor: 1PCS
Power Adapter: 1PCS
User Manual: 1PCS
